Subaru Forester: Parking Distance Warning (PDW): (if equipped) / Parking Distance Warning operation

Parking Safety button

Simply press the physical Parking Safety () button on the center console to manually turn ON the Parking Distance Warning feature. Pressing the button a second time will manually disengage and turn OFF the system monitoring function.

Whenever you shift the automatic transmission gear selector into R (Reverse), the Kia Telluride Parking Distance Warning system will automatically switch ON by default, which is visually confirmed when the integrated Parking Safety button indicator LED turns ON.

Forward Parking Distance Warning

The Forward Parking Distance Warning system in your Kia Telluride actively engages to assist with low-speed maneuvering whenever any of the following operational conditions are satisfied:

• Directly after shifting the transmission gear selector from R (Reverse) to D (Drive) while the Reverse Parking Distance Warning feature is currently active and turned ON.

• Whenever the transmission selector is shifted into D (Drive) and the console-mounted Parking Safety () button indicator light remains illuminated.

• The Forward Parking Distance Warning actively alerts you while driving in D (Drive) provided you have previously enabled the automatic feature by navigating on the Kia Telluride infotainment system screen to Setup > Vehicle > Driver Assistance > Parking Safety > Parking Distance Warning Auto On.

TIP

Warning indicator and warning sound

Distance from object	Warning indicator		Warning sound
	Instrument cluster	Infotainment system screen
24–48 in (60–120 cm)			Buzzer beeps intermittently
12–24 in (30–60 cm)			Buzzer beeps more frequently
within 12 in (30 cm)			Buzzer beeps continuously

• The designated visual graphic appears on screen and an acoustic alert chime sounds concurrently whenever any active ultrasonic sensor detects a person, animal, or stationary object within its immediate detection zone.

• When multiple physical objects (more than 2) are detected simultaneously on the Kia Telluride perimeter, the audible alert prioritize and warns for the nearest obstacle.

• Please note that the exact graphic style or visual layout shown in these manual illustrations may vary slightly depending on your specific Kia Telluride model year and cluster software version.

Side Parking Distance Warning: (if equipped)

The integrated Side Parking Distance Warning system provides supplemental perimeter protection for your Kia Telluride, operating whenever any of the following parameters are active:

• When the driver shifts the automatic transmission selector directly into R (Reverse).

• When the vehicle gear selector is in D (Drive) and the center console Parking Safety () button light is illuminated.

• While current vehicle ground speed stays reliably below 6 mph (10 km/h).

TIP

Warning indicator and warning sound

Distance from object	Warning indicator		Warning sound
	Instrument cluster	Infotainment system screen
24–48 in (60–120 cm)			-
12–24 in (30–60 cm)			-
within 12 in (30 cm)			Buzzer beeps continuously

• Whenever a side ultrasonic sensor detects a person, structure, or object nearby, the instrument cluster panel and central infotainment display present distinct visual warning icons relative to the measured clearance.

• An intense audible warning chime sounds continuously when a side obstacle is detected within 12 in (30 cm) inside the immediate vehicle turning arc or exit trajectory.

• If an object is situated along the side but outside of the direct vehicle turn clearance trajectory, the Kia Telluride system displays silent visual indicators only without sounding the chime.

• While moving in D (Drive), if the lateral distance to a side object equals or exceeds 12 in (30 cm), the instrument cluster suppresses the side-way visual warning graphics.

• Screen iconography and visual indicators shown in manual diagrams may present minor design differences compared to the active display in your Kia Telluride.

Reverse Parking Distance Warning

The Reverse Parking Distance Warning system automatically activates to assist with safe backing procedures whenever you shift the transmission gear selector into R (Reverse) in your Kia Telluride.

TIP

Warning indicator and warning sound

Distance from object	Warning indicator		Warning sound
	Instrument cluster	Infotainment system screen
24–48 in (60–120 cm)			Buzzer beeps intermittently
12–24 in (30–60 cm)			Buzzer beeps more frequently
within 12 in (30 cm)			Buzzer beeps continuously

• The corresponding visual indicator appears on screen and an clear audible warning chime sounds whenever each rear ultrasonic sensor detects a person, animal, or physical object within its active sensing range.

• When more than 2 objects are detected at the same time along the rear bumper area, the system priority shifts so that the audible warning applies to the closest one.

• The specific shape or visual design of the indicator in the manual illustration may differ slightly from the active graphic displayed by your specific Kia Telluride trim level.
