Setting the Ergo-motion seat

The Ergo-motion seat in the Kia Telluride uses adjustable air pockets to provide customized cushioning and support for the driver. By changing the support around the hips, waist, and lumbar area, this feature helps reduce fatigue and improve comfort during long drives, continuous highway travel, or changing driving conditions.

Seat Ergo-motion seat Comfortable stretch Posture Assist Lumbar Stabilization System while driving

Operation

• Select Setup > Vehicle > Seat > Ergo-motion seat from the infotainment system.

Ergo-motion seat modes

Comfort stretching

Operation

• Each time the comfort stretch control switch on the driver's door is pressed, the mode changes in sequence and the selected mode appears on the infotainment system screen.

  • Pelvic stretching: The cushion section moves to help the pelvis shift gently from side to side.

  • Lumbar stretching: The lumbar support moves to help exercise the front and rear areas of the waist.

  • Whole body stretching: The cushion and lumbar support move sequentially to help relieve fatigue across the body.

  • Off: The comfort stretching function is disabled.

• Comfort Stretching can be turned off by pressing and holding the switch for approximately 1 second or longer while the function is operating.

• If any seat adjustment switch, including cushion support, lumbar support, or the bolster adjustment device, is pressed while Comfort Stretching is operating, the function stops.

• Select Setup > Vehicle > Seats > Ergo-motion seat > Comfortable stretch from the infotainment system to adjust the intensity and duration of the comfort stretching feature.

  • Intensity: Normal / Strong

  • Duration: Short (10 min.), Normal (15 min.), Long (20 min.)

Posture assist

After approximately one hour of driving with the driver's seat belt fastened, the posture assist function automatically activates. It helps support the driver's posture by adjusting the hip and waist areas of the driver's seat, making long-distance driving in the Kia Telluride more comfortable.

Operation

• Select Setup > Vehicle > Seats > Ergo-motion seat > Posture Assist from the infotainment system.

• If a seat adjustment switch, such as cushion support, lumbar support, or the bolster adjustment device, is operated while posture assist is active, the function stops.

Operating condition(s)

When both of the following conditions are satisfied, the posture assist function automatically operates to help maintain a more comfortable driver seating position.

• The vehicle is in ON position.

• The driver's seat belt is fastened.

Lumbar Stabilization System while driving

This function repeatedly adjusts the lumbar support in a regular pattern to help reduce back fatigue during continuous driving. It is designed to provide gentle movement and support for the lower back when the Kia Telluride is driven for an extended period.

Operation

• Select Setup > Vehicle > Seats > Ergo-motion seat > Lumbar Stabilization System while driving (Off, 30 min, 1hour) from the infotainment system.

• If the lumbar support adjustment switch is pressed while the lumbar support function is operating during driving, the function stops.

Operating condition(s)

• The function activates automatically after 30 minutes or 1 hour of continuous driving, depending on the setting selected in the infotainment system.
